Discover our latest RF innovations for the future of wireles
Electronic RF BUY introduces its latest innovations in RF antennas and advanced wireless connectivit
Engineered for performance, reliability, and next-generation networks, our products support IoT, 5G, and future-ready Wi-Fi technologies.
Discover our new generation of high-performance RF solutions and antennas designed to meet the demands of modern wireless technologies.
Specification:
1. 2.4/5.8Ghz
2. < 2.5dBi peak gain
3. Up to 60-95% transmission efficiency
4. Frequency and size can be matched to the internal space of the mainframe.
5. Flexible cable can facilitate the conversion of antenna direction
Features.
1. Antenna
- Frequency range 2.4/5.8Ghz
- Gain < 5/2.5dBi
- V.S.W.R < 2.0
- Impedance50Ω
- Polarization N/A
- Power 10W
2.Mechanical
- Inner structure PCB
- External structure N/A
- Antenna size 116*22MM
- Cable type RF 3M cable or optional
- Connector type Right angle SMA male or optional
- Mounting method Adhesive mount
3.Environmental
- Operating temperature -40℃~+80℃
- Storage temperature -40℃~+85℃
- Environmentally friendly ROHS compliant
- Humidity range 0% to 95% non-condesing
Specification:
1. 2400-2500/5150-5850/5925-7125MHz.
2. < 2.3/5/2.5dBi peak gain
3. Up to 60-95% transmission efficiency
4. Frequency and size can be matched to the internal space of the mainframe.
5. Flexible cable can facilitate the conversion of antenna direction
Features.
1. Antenna
- Frequency range 2400-2500/5150-5850/5925-7125MHz.
- Gain < 2.3/5/2.5dBi
- V.S.W.R < 2.0
- Impedance50Ω
- Polarization N/A
- Power 10W
2.Mechanical
- Inner structure PCB
- External structure N/A
- Antenna size 35.20*8.50MM
- Cable type RF 500MM cable or optional
- Connector type Right angle SMA male or optional
- Mounting method Adhesive mount
3.Environmental
- Operating temperature -40℃~+80℃
- Storage temperature -40℃~+85℃
- Environmentally friendly ROHS compliant
- Humidity range 0% to 95% non-condesing
Specification:
1. 14dBi peak gain
2. FPV panel antenna
3. Up to 70%-80% transmission efficiency
4. Selectable size/frequency/connector
Features.
1. Antenna
- Frequency range 5150-5850MHz
- Gain 14dBi
- V.S.W.R < 2.0
- Impedance 50Ω
- Polarization Vertical
- Power 10W
2.Mechanical
- Inner structure PCB
- External structure PC+PBT/TPEE
- Antenna size 122*60*9.5MM
- Cable type RG141 cable
- Connector type SMA male or optional
- Mounting method Adhesive mount
3.Environmental
- Operating temperature -40℃~+80℃
- Storage temperature -40℃~+85℃
- Environmentally friendly ROHS compliant
- Humidity range 0% to 95% non-condesing
2.4 -2.5G External Directional Antenna
Specification:
1. 14dBi peak gain
2. FPV panel antenna
3. Up to 70%-80% transmission efficiency
4. Selectable size/frequency/connector
Features.
1. Antenna
- Frequency range 2.4-2.5GHz
- Gain 8.22dBi
- V.S.W.R 2:0
- Impedance 50Ω
- Polarization Vertical
- Power 10W
2.Mechanical
- Inner structure Tinplate
- External structure ABA/POM
- Antenna size 108.5*90MM
- Cable type RF1.37
- Connector type SMA male or optional
- Mounting method Adhesive mount
3.Environmental
- Operating temperature -40℃~+80℃
- Storage temperature -40℃~+85℃
- Environmentally friendly ROHS compliant
- Humidity range 0% to 95% non-condesing
